CHOOSE QUALITY,CHOOSE JCROOF
Stone Coated metal roof tile
- 11+ years in stone coated metal roof tile industry.
- The Top 3 Stone Coated metal roof tile exporter in China.
Elite Tile Stone Coated Metal Roofing
The Elite Tile is a premium composite roofing material meticulously engineered with a sleek, low-profile flat design that features subtle, refined striations. It perfectly replicates the sophisticated, minimalist aesthetic of natural slate or premium flat shingles, while delivering the industrial-grade strength and extreme weather resistance of metal. The core consists of high-quality Galvalume steel (PPGL), completely coated with high-temperature sintered natural basalt stone chips and bonded with a premium acrylic resin system.
Backed by 11 years of manufacturing expertise, our factory operates 6 fully automated, high-precision production lines, maintaining a stable weekly output of over 140,000 pieces. Manufactured under strict ISO9001 quality management systems, this product carries comprehensive international trade compliance certifications including CE, SONCAP, and COC. It is the ultimate modern roofing solution, offering global distributors and contemporary project developers a highly durable, low-maintenance system with an elegant, seamless architectural finish.
Technical Specifications
| Property | Specification Data |
|---|---|
| Profile | Elite Tile |
| Base Material | Galvalume steel (Aluminum Zinc plated steel sheet=PPGL) |
| Surface Coating | Natural Stone Chips |
| Adhesive | Modified Acrylic Resin |
| Overall Size | 1680 mm × 420 mm |
| Effective Size | 1630 mm × 400 mm |
| Thickness | 0.35mm,0.38mm,0.40mm, 0.45mm,0.50mm,0.55mm and others(0.2-0.6mm) |
| Weight per Piece | 2.35 kg — 3.50 kg |
| Coverage Area | 0.71 sq.m. / pc |
| Tiles per Sq.m. | 1.42 pcs |
| Certificate | SONCAP, COC, UL, ISO9001, CE |
| Applications | Residential roofs, commercial renovations |
Key Technical Features
1. Minimalist Slate Aesthetics & Structural Seamlessness
Sleek Flat Profile: The Elite Tile eliminates high-barrel curves in favor of a streamlined, flat geometry with shallow textured ripples. This provides a clean, continuous visual plane highly sought after in modern and contemporary architecture, offering the luxury of natural slate without the crushing weight or high installation costs.
Seamless Interlocking Matrix: Despite its flat appearance, it utilizes a highly engineered hidden interlocking system. Once installed on standard battens, the tiles lock together to form a rigid, impenetrable shield that prevents water infiltration even during horizontal, wind-driven rain.
2. Extreme Environmental Tolerance
Aerodynamic Wind Defense: The continuous flat and sleek profile naturally generates minimal wind resistance. It seamlessly interlocks to create a tight, unified roof matrix. When installed with standard batten systems, this low-profile aerodynamic design severely disrupts and deflects high-velocity winds, offering exceptional defense against hurricane-force uplift compared to highly curved tiles.
Corrosion & UV Defense: The high-grade aluminum-zinc alloy electroplating creates a dual protective film on the steel plate. Paired with high-temperature sintered basalt granules, it ensures zero rusting and vibrant color durability under intense UV exposure or in harsh marine environments.
Stone Coated Metal Roof Panel Components
Overglaze – semi-gloss finish; added protection
Stone Granules – color; UV resistance; coverage
Basecoat – adhesion; UV protection; color blended
Acrylic Primer – priming system; enhances adhesion
Aluminum-Zinc Alloy Coating – prevents corrosion; protection
Steel – 0.2mm to 0.6mm thickness; load-bearing; flexible
Aluminum-Zinc Alloy Coating – prevents corrosion; protection
Acrylic Primer – priming system; enhances adhesion
In general, there are 3 main parts of raw material contents:
① Stone Chips ( Beautiful look, effective heat / UV resistant, noise reduction, anti-slip and etc features)
② Galvalume Steel Plate ( Eco-friendly and recyclable material, strong, light-weight, anti-corrosion, waterproof)
③ Acrylic Glue ( Premium sealing performance, strong adhesion, anti-algae)
Supply Chain & Quality Control (QA/QC)
Premium Raw Material Supply: Our metal substrates are sourced from leading domestic steel mills, guaranteeing the yield strength and coating uniformity of the steel from the source.
Automated Production Control: Our 6 continuous production lines utilize automated spraying and constant temperature baking processes. This minimizes batch to batch variation, ensuring consistent acrylic resin thickness and strict adherence to factory standards for stone chip adhesion.
Authoritative Compliance: To meet the access requirements of different countries, every shipment is supported by comprehensive CE, ISO9001, SONCAP, and COC testing reports and documentation to facilitate rapid customs clearance.
Logistics & International Packaging Standards
To ensure cargo integrity during long-distance ocean freight and multimodal transport, we provide standardized, heavy-duty export packaging solutions:
Packaging Format: Fumigated wooden pallets for export + multi-layer PE waterproof wrapping + overall steel strapping reinforcement. Inner packaging can be customized (e.g., 10 pieces per bundle) according to procurement requirements.
Pallet Load Capacity: Standard loading capacity ranges from 500 to 900 pieces per pallet (optimized based on steel thickness and destination port weight limits).
Container Loading Efficiency: A standard 20ft General Purpose (GP) container can accommodate a maximum of 20 pallets. Our logistics team provides precise loading plans tailored to different national port weight regulations, maximizing container volume utilization while preventing cargo shifting during transit.
Why Stone Coated Metal Roof？
50
years
0.4-0.8mm thick steel sheet with 150g/m2 galvanized aluminum zinc rust-proof coating, providing A-grade rust resistance, lifespan of 50 years without corrosion or perforation.
Noise Reduction
Same sound insulation ability as ceramic roof tiles or asphalt shingles, no need to be disturbed by the sound of rain.
fire proof
Made of steel material, A-class fire resistance, safer and more reassuring.
Hail Prevention
Ceramic tiles or PVC tiles can be damaged in hail weather, but for metal tiles 0 worry!
Hurricane Resistance
Lightweight yet sturdy, able to effectively withstand strong wind of 60-80MPH.
Weather Resistant
With UV resistant high quality surface glue, and high temperature colored baking stone chips, 15+ years no worry of color fading issue.
light weight
Only 5-8Kg per square meter, the weight is only 16% of traditional ceramic tiles, greatly reduces the load-bearing capacity of building structures.
Environmental
Metal material and natural stone, without any pollution issues.
Low Maintenance
No damage or other minor issues, benefit from one installation for a lifetime.
Cost Effective
Compared to other types of roof tiles, there is no significant increase in cost.
Technical documents
More designs that we have
A Global Supplier of Stone CoatedSteel Roofing Solutions
Our quality products are completed and each item is available for purchase and customer approval. We offer first-class quality and the most exquisite design.
